| Product & Code |
FIXED BED REACTOR & CRE 51 |
| Reactor tube |
Reactor tube for reaction with flanges and gasket, catalyst bucket, with provision for thermocouple and reactant inlet and product outlet:
Dimension: 25.4 mm ID x 500 mm L; MOC: SS 316; Pressure: Atmospheric |
| Thermocouple and temperature indicator |
Temperature: Upto 1000oC |
| Furnace for the Reactor |
Furnace for the Reactor heating with PID controller: Electric furnace heating, tube type; 2 zones; Temperature: Upto 1000oC |
| Furnace for pre heating |
Furnace for pre heating with PID controller: Electric furnace heating, tube type; Temperature: Upto 350Oc |
| Tube |
Tube for the pre heating and reactant inlet and product outlet provisions: Dimension: 16.4 mm ID x 300 mm L; MOC: SS 316; Pressure: Atmospheric |
| Iron Frame base |
for holding the reactor, pre heater system and peristaltic pump |
