FM-HBA-14 PITOT STATIC TUBE (HYDRAULIC BENCH ACCESSORIES)

DESCRIPTION

A Pitot tube is used to measure the local velocity at a given point in the flow stress. A Pitot tube of standard design made of copper/Stainless Steel is supplied and is fixed below a vernier scale. The vernier scale is capable to measure the position of Pitot tube in transparent pipe section. The pipe has a flow control valve to regulate the flow. A manometer is provided to determine the velocity head.


RANGE OF EXPERIMENTS

  • To find the point velocity at the center of a tube for different flow rates of meter and calibrate the pitot tube
  • To find the co-efficient of Pitot tube
  • To study the flow distribution in a pipe and estimate the ratio of average velocity to maximum velocity at the center of pipe for different flow rates
  • To plot velocity profile across the cross section of pipe for different Reynold’s number.


FEATURES

  • Clear Acrylic test section
  • Superb Painted structure
  • Simple to operate & maintain


UTILITIES REQUIRED

  • Hydraulic Bench.
  • Water Supply & Drain
  • Electricity 1 kW, 220V AC, Single Phase
  • Floor Area 1.5 x 1.5


TECHNICAL SPECIFICATIONS

Product PITOT STATIC TUBE (HBA)
Pitot Tube Material Copper/ SS of compatible size.
Hook/Pointer Gauge With Vernier Scale
Test Section Material Clear Acrylic, compatible to 1″ Dia. Pipe.

The whole setup is well designed and arranged in a good quality painted structure.
