MT 23 MASS TRANSFER WITH/WITHOUT CHEMICAL REACTION (SOLID-LIQUID SYSTEM)

DESCRIPTION



The set-up is designed to demonstrate and study the mass transfer with/without chemical reaction in a solid-liquid system.

The set up consists of Stainless Steel Baffled Reactor placed in a water bath. The reactor is fitted with a variable speed stirrer shaft. In place of agitator a solid cylinder of Benzoic Acid is stirred in the reactor. This arrangement is done by using a Peltilizer provided with the set up. The temperature of reactor via water bath can be independently varied to simulate different conditions using digital temp. Controller.



EXPERIMENTS

  • Dissolution of Benzoic acid in water: Kinetic studies
  • Dissolution of Benzoic acid with reaction in aqueous NaOH solution



FEATURES

  • Superb Painted structure
  • Simple to operate & maintain
  • Compact & stand alone set up



UTILITIES REQUIRED

  • Water Supply & Drain
  • Electricity Supply: 1Phase, 220 V AC, 0.5 kW
  • Instruments, Laboratory Glassware and Chemicals required for analysis as per the system adopted

TECHNICAL SPECIFICATIONS

Product & Code Mass Transfer With/Without Chemical Reaction & MT 23
Reactor Material Stainless Steel, Capacity 2 Ltrs. (approx)
Water Bath Material Stainless Steel, Double Wall, insulated with ceramic wool fitted with Nichrome Wire Heater
Stirrer Stainless Steel Impeller and shaft coupled with variable speed motor .
Temp. Measurement RTD PT-100 type Temp. Sensors
Control panel RPM Indicator: Digital, Non contact type Digital Temp. Controller 0- 199.9°C for water bath, On/off switch, Mains Indicator etc.
Peltilizer Suitable Size

The whole setup is well designed and arranged in a good quality painted structure.
