TD 13 VORTEX TUBE REFRIGERATION SYSTEM

RANGE OF EXPERIMENTS

  • Observe the Temperature separation phenomenon of vortex tube.
  • The experiments can be conducted at various of input pressure.



EXPERIMENTAL SETUP

  • Vortex tube assembly
  • Pressure control valve.
  • Two Separate Chambers.
  • Nozzle, Diaphragm & orifice asse mbly



Computer controlled via USB interface with complete educational software including data logging, graph plotting, data export.
