TOM 01 UNIVERSAL VIBRATION APPARATUS

DESCRIPTION

The apparatus provided comprehensive unit to perform the vibration experiments. A universal frame is provided upon which quick and easy assembly of various experiments can be done. The unit is self-contained to safely store spares. The students can easily assemble the experiments and study the theory of vibrations practically.


RANGE OF EXPERIMENTS

  • Following experiments can be performed with this unit:
  • • To verify the relation simple pendulum
  • • To verify the relation of compound pendulum & to determine the radius of gyration.
  • • To study radius of gyration of bi-filer suspension
  • • To study the un damped free vibration of spring mass system
  • • To study the longitudinal vibration of helical coiled spring
  • • To study the forced vibration of simply supported beam for different damping.
  • • Un damped torsional vibrations of single rotor system
  • • Un damped torsional vibrations of double rotor system
  • • To study the damped torsional vibration of single rotor system and to determine the damping co- efficient
  • • Verification of Dunkerley's Rule
  • • To study the forced damped vibration of spring mass system


FEATURES

  • • Floor Space: 2.5 m x 2.5 m approx.
  • • Power Supply: 230V AC. 5 Amp with earth


UTILITIES REQUIRED

  • • Compact & stand alone set up
  • • Superb Painted structure
  • • Simple to operate & maintain


TECHNICAL SPECIFICATIONS

Product & Code Universal Vibration Apparatus & TOM 01
RPM measurement Digital RPM Indicator with Proximity sensor
Control Panel Comprises of Speed Control unit & RPM Indicator

The set-up also consists of exciter unit with FHP Motor and speed controller ordinary strip chart recorder and damper with arrangement for changing damping. An electronic stop clock is provided to measure the time period.
