Item Code Description
ED 01 1 C 4 S Diesel Engine Test Rig (Brand New Kirloskar Engine), With Stainless Steel Exhaust gas calorimeter & digital tachometer

(i) Rope brake dynamometer with loading unit

(ii) Electrically Dynamometer with loading unit

(iii) Hydraulic Dynamometer with loading unit

(iv) Eddy current dynamometer with loading unit

ED 02 2 C 4 S Diesel Engine Test Rig (Brand New Engine), With Stainless Steel Exhaust gas calorimeter & digital tachometer

(i) Rope brake dynamometer with loading unit

(ii) Electrically Dynamometer with loading unit

(iii) Hydraulic Dynamometer with loading unit

(iv) Eddy current Dynamometer with loading unit

ED 03 4 C 4 S Diesel Engine (Sparingly used refurbished) Test Rig With Battery & Charger, Stainless Steel, Exhaust gas calorimeter digital tachometer

(i) Rope brake dynamometer with loading unit

(ii) Electrically Dynamometer with loading unit

(iii)Hydraulic Dynamometer with loading unit

(iv) Eddy current dynamometer with loading unit

ACTUAL CUT SECTION ENGINES

Item Code Description
ED 05 1 C 4 S Diesel Engine actual cut section valve timing diagram
EP 06 1 C 4 S Petrol Engine actual cut section valve timing diagram
EP 07 1 C 2 S Petrol Engine actual cut section Port timing diagram

ENGINE SETUPS – PETROL (COMPUTERIZED)

Item Code Description
ED 01 COMP Computerised 1Cylinder, 4 Stroke, Diesel, Kirloskar TV1, constant speed, Power 5.2 kw @ 1500 rpm, 661cc with eddy current dynamometer
ED 02 COMP Computerised 2 Cylinder, 4 Stroke, CRDI Diesel, Maxximo BS IV, Power 18.4 KW @ 3600 rpm, 909cc with eddy current dynamometer
ED 03 COMP Computerised 4 Cylinder, 4 Stroke, Turbo Diesel, Maruti Swift CRDI BS IV, Power 70 PS @ 4500 rpm, 1405cc with eddy current dynamometer
ED 04 COMP Computerised VCR engine setup 1Cylinder, 4 Stroke, Diesel with EGR, constant speed, Power 3.5 kw @ 1500 rpm, CR range 12-18:1 with eddy current dynamometer. (with electric start)
ED 05 COMP Computerised VCR engine setup Single cylinder, CRDI with EGR and Open ECU 1Cylinder, 4 Stroke, Diesel, constant speed, Power 3.5 kw @ 1500 rpm, CR range 12-18:1 with eddy current dynamometer
